Sunix SER6437PHL 2-port RS-232 High Speed PCI Express Low Profile Board

Discover the Power of Sunix SER6437PHL 2-port RS-232 High Speed PCI Express Low Profile Board with Power Output

Unleash the full potential of your serial communication with the Sunix SER6437PHL. This amazing 2-port RS-232 High-Speed PCI Express Low Profile Board with Power Output offers incredible value and unrivaled affordability. Designed for seamless integration and exceptional performance, this board is a game-changer for any tech enthusiast.

Specifications:

Interface: RS-232
Controller: SUNIX SUN2212 (16C950 UART Compatible)
BUS: PCI Express Spec 2.0, Single-Lane (x1)
IRQ & IO: Assigned by System

Serial Communication:

No. of Port: 2-port
FIFO: 128byte Hardware
Signal: DCD, TxD, RxD, RTS, CTS, DTR, DSR, GND, RI/12V/5VDC
Baud rate: 50bps ~ 921.6Kbps
Stop bit: 1, 1.5, 2
Parity: even, odd, none, mark, space
Flow Control: None, Xon/Xoff, RTS/CTS
Protection: ±15KV ESD protection for each signal Human Body Model (HBM), ±15KV IEC1000-4-2 Air Gap Discharge, ±8KV IEC1000-4-2 Contact Discharge
PCB Connector: DB44 Female

Driver Support:

Windows Client: XP / Vista / 7 / 8.x / 10 (X86/X64) / 11
Linux: Linux 2.x / 3.x / 4.x / 5.x
DOS: DOS
*UNIX: FreeBSD / QNX / SCO OpenServer / SCO UnixWare / Solaris

Regulatory Approvals:

Hardware: CE, FCC, VCCI, BSMI
Software: Microsoft WHQL Windows

Operation Temperature: 0 to 60°C (32 to 140°F)
Operation Humidity: 5 to 95% RH
Storage Temperature: -20 to 85°C (-4 to 185°F)

Dimension:

PCB Dimension: 77 x 68 mm
Bracket: Low Profile 80 mm
Bracket Space: 1

Don't miss out on the opportunity to enhance your serial communication experience with the Sunix SER6437PHL Low Profile Board. Get yours before it's gone!

Take your serial communication to the next level with the Sunix SER6437PHL. Add it to your cart today!
